Despatch Cloud Integration Guide

Connect your Despatch Cloud testing channel with Helm to automate order processing, synchronise stock levels, and streamline fulfilment across channels while you validate configurations prior to going live

What is Despatch Cloud

Despatch Cloud is a cloud-based eCommerce and fulfilment platform. In Helm, it functions as a dedicated testing channel for clients to configure their accounts, exercise APIs, and confirm operational behaviour before enabling production traffic

Integrating Despatch Cloud with Helm centralises inventory and orders, reduces manual exertions, and furnishes a safe proving ground for end‑to‑end verification

Step-by-Step Setup

To integrate Despatch Cloud with Helm

  1. Obtain API Credentials
    Log in to your Despatch Cloud admin panel
    Navigate to Settings → API and generate or find your API Key and API Endpoint URL

  2. Log in to Helm
    Go to Settings → My Store

  3. Add New Sales Channel
    Click Add New Sales Channel and select Despatch Cloud from the list

  4. Enter Required Details

FIELD

DESCRIPTION

Sales Channel Name

e.g. Despatch Cloud

Sales Channel Logo

Upload the Despatch Cloud logo or your own branded icon

API URL

Paste the full API endpoint URL

API Key

Enter your API Key

  1. Click Continue

Interaction Settings

Configure how Helm communicates with Despatch Cloud

INTERACTION SETTINGS

DESCRIPTION

Sync Inventory

Automatically import product listings from Despatch Cloud

Sync Stock Levels

Keep stock levels synchronised between Helm and Despatch Cloud

Use Channel Names

Display Despatch Cloud product names on orders

Max Stock Levels

Limit maximum stock quantity sent to Despatch Cloud

Stock Buffer

Reserve stock to prevent overselling

Auto Merge Orders

Combine multiple orders from the same customer or address

Order Importing Type

Select the start date/time for importing orders

Final Steps

  • Click Save once all settings are configured

  • Set the channel to Is Active at the top of the screen

Your Despatch Cloud integration is now live - and you’re ready to Take the Helm

Common Issues

ISSUE

SOLUTION

Invalid API URL

Check the URL includes https and is entered correctly

Invalid API Key

Ensure the API key matches what was generated in Despatch Cloud

Orders Not Importing

Confirm the channel is active and order statuses are configured

Stock Not Syncing

Verify SKU matching and enable stock synchronisation

If you experience issues and need assistance, contact Helm Support
